Overview
Quick Details
Place of Origin:
- Shandong, China
Brand Name:
- Gelon
Model Number:
- BK-300A
Product name:
- Lithium Battery Testing Machine
Application:
- Battery Internal Resistance Testing
Warranty:
- 1 Year
Type:
- BK-300A, BK-600A
Size:
- 340 x 380 x 110 mm
Way of tester:
- Four-line measurement
Weight:
- About 6kg
Voltage:
- 220V
Certificate:
- CE Certificate
Ac current frequency:
- KHZ±0.1KHZ
Packaging & Delivery
Selling Units:
Single item
Single package size:
38X34X11 cm
Single gross weight:
6.0 kg
Package Type:
Standard Export Package of Lithium Battery Testing Machine
Picture Example:
Lead Time :
Quantity(Sets) 1 - 2 >2 Est. Time(days) 20 To be negotiated
Product Description
Li-ion Battery Test Equipment Internal Resistance Battery Testing Machine BK-300A
BK-300 is a precision internal resistance meter for R&D or quality control of all rechargeable battery, which has accuracy up to 1milli-ohm and can measure any battery from 0-19.99V. One battery holder and cable are included and allow you measure cylinder cell and battery pack at easy.
SPECIFICATION FOR BATTERY TESTING MACHINE BK-300A | |||
BK-300A | Type of tester | Ac internal resistance tester | Working temperature: 20℃±5℃ |
Way of tester | four-line measuremen | Holder:Air plug,can holder box or testing line | |
Ac current frequency | 1KHZ±0.1KHZ | Calibration:Potentiometer calibration | |
Voltage | Voltage: Two selectable ranges | ||
DC0~5.000V | resolution 1 mV | Accuracy±(0.2%rdg+5dgt). | |
DC5.00v~20.00V | resolution 10mV | Accuracy±(0.2%rdg+5dgt) | |
Internal resistance | Battery internal resistance | Two selectable ranges | |
Low range: 3mΩ~300.0mΩ | Current 10mA | ±0.3%rdg+5dgt. | |
High range: 300mΩ~3000mΩ | Curent 1mA | ±0.3%rdg+5dgt. | |
