| Technical specifications | |
| Sanding board Width (Max) | 1300mm |
| Sanding board thickness | 4-40mm |
| Sanding board length | >2000mm |
| Abrasive belt speed | 25m/s |
| Abrasive belt dimension | 1350x2800mm |
| Total capacity of motors | 163.25Kw |
| Motor for sanding head | 75Kw x 2 |
| Motor for feed | 11Kw |
| Motor for lifting | 0.75Kw |
| Motor for brush | 0.75Kw x 2 |
| Feed Speed | 10-30m/min |
| Power supply | 380V 50Hz |
| Operating Pressure | 0.6-0.8MPa |
| Capacity of suction extraction | 24000m3/h |
| Dimension | 3020 x 3100 x 3120mm |
| Net weight | 15500kg |
